| Overall Dimensions | |
|---|---|
|
Outside Diameter (Do)
|
33.534 in. |
|
Inside Diameter (Di)
|
23.125 in. |
| Overall Height (H) | 2.875 in. |
| Ring Height (Hi/Ho) | 2.563 in. |
| Weight | 283 lbs. |
| Mounting Holes | |
|---|---|
|
Outer Bolt Circle Diameter (OBC)
|
30.625 in. |
| OBC Hole Count | 18 |
|
OBC Hole Diameter (Bo)
|
0.938 in. |
|
Inner Bolt Circle Diameter (IBC)
|
24.875 in. |
| IBC Hole Count | 24 |
|
IBC Hole Diameter (Bi)
|
0.938 in. |
| Gear Data | |
|---|---|
| Tooth Form | SD |
| Pressure Angle | 20° |
| Pitch Diameter | 33 in. |
| Diametral Pitch | 3 |
| Tooth Count | 99 |
| Face Width | 2.563 in. |
| Max Gear Tooth Load | 17290 lbs. |
| Load Capacities | |
|---|---|
| Static Axial Capacity | 496207 |
| Static Radial Capacity | 157109 |
| Static Moment Capacity | 216721 |
We produce precision-engineered mating pinions designed to work seamlessly with our bearings. Contact us to have a member of our team help you find the right pinion.
