4 DP14 teethIntegral shaft bore
P004.14.050.HR.000 Pinion
SlewPro pinion P004.14.050.HR.000: 14 teeth, 4 DP, 3.500" pitch diameter, 0.50" face, integral shaft bore. Built to order for slewing ring gear drives.
Specifications
| Part number | P004.14.050.HR.000 |
|---|---|
| Diametral pitch | 4 DP |
| Number of teeth | 14 |
| Pitch diameter | 3.500 in |
| Pressure angle | 20° |
| Tooth form | Involute Stub |
| Face width | 0.50 in |
| Outside diameter | 3.900 in |
| Hub | Hub |
| Bore type | Integral shaft |
| Bore detail | Pinion shaft, 4.20" overall length |
| Approx. weight | 2 lb |
From our engineering drawing and 3D model. Need a different bore or face width? We modify pinions to suit.
