3 DP14 teethSplined bore
P003.14.405.NS.000 Pinion
SlewPro pinion P003.14.405.NS.000: 14 teeth, 3 DP, 4.667" pitch diameter, 4.05" face, splined bore 1.083". Built to order for slewing ring gear drives.
Specifications
| Part number | P003.14.405.NS.000 |
|---|---|
| Diametral pitch | 3 DP |
| Number of teeth | 14 |
| Pitch diameter | 4.667 in |
| Pressure angle | 20° |
| Face width | 4.05 in |
| Outside diameter | 5.200 in |
| Hub | No hub |
| Bore type | Splined |
| Bore diameter | 1.083 in (27.5 mm) |
| Bore detail | Splined bore |
From our engineering drawing and 3D model. Need a different bore or face width? We modify pinions to suit.
CAD & documents
Get this pinion
Request a QuoteTalk to an engineer
Need help selecting the right part? Our engineers will size it, cross it, and quote it — usually within 1–2 business days.
Not in the catalog? We design to your application, with no engineering charge.
